Cemintel Mosaic® Cladding

Name: Cemintel Mosaic® Cladding
Brand: CSR Cemintel
SKU: 123280
Availability: InStock

SKU:

123280

Category:

Cladding & Facade

$0.00

Tax included.

Specification: 1190x2990x8mm

1190x2990x8mm

In Stock - CSR Cemintel

Pickup Available

Delivery Available

Best Price

Guarantee

Bulk Order

Discounts

Fast Perth

Delivery

Trusted by

Trade

An 8mm square-edge cladding panel sized 10mm short of standard sheet dimensions, creating a 10mm expressed joint gap that frames each panel in stack-bond, stretcher-bond or custom geometric layouts. Site-painted, brad-nail fixed and installed as part of a cavity system with vertical battens and horizontal backing strips; typically used as a feature-wall treatment.

Product Code: 123280
Web Description: Mosaic Cladding
Width(mm): 1190
Length(mm): 2990
Thickness(mm): 8
Surface Texture: Smooth
Finish: Preprimed
Groove Spacing (mm): n/a
Effective Cover Per Unit (m2): 3.56
Effective Width (mm): 1190
Mass (kg/m2): 12.6
Weight Per Unit: 44.86
Product Warranty (Years): 10
BAL: BAL-29

Key Features:
Smooth finish panels for exterior paint or textured aggregate finishes.
Brad nail fixing minimizes surface disruption and patching.
“Cladding will not rot, burn or corrode and is unaffected by termites, air, steam, salt and sunlight” (installation guide p3)
Pre-primed face, back with black sealer on the sides.

Technical Resources

Warranty - Mosaic Cladding
Warranty - Cemintel Trims
Safety Data Sheet - Fibre Cement
Fire Performance Report - Fibre Cement Cladding
Design & Installation Guide - Mosaic Cladding
Design & Installation Guide - Facades and Cladding
Design & Installation Guide - Cavity Wall Cladding Systems
Flyer - Cemintel Trims
Brochure - Streetstyle
Technical Data Sheet - Mosaic Cladding
BIM File - Mosaic Cladding

Mosaic Cladding Installation

Mosaic cladding is not pre-finished, it’s site painted. Designers can take advantage of the vast array of available exterior paint colours. Metallic paint can make it look like high-end express joint metal cladding.

The geometric express joint cladding systems used on commercial buildings, such as Surround Cladding, use a metal top hat fixing system. To make Mosaic cost-effective for detached houses, the express joint cladding system uses fibre cement battens instead of metal top hats.

The fibre cement cavity battens are used for the vertical express joints. ExpressWall® Backing Strips are used for the horizontal express joints.

Being fibre cement, Mosaic cladding is deemed suitable for use in applications where non-combustible materials are specified. As per the National Construction Code Volume One clause C2D1 Deemed-to-Satisfy Provisions (6) (d).

Suitable for Bushfire Attack Level up to BAL-29 when constructed in accordance with Australian Standard AS3959.
